The Accumul8 Retriever is a skid steer loader mounted bale accumulator with an integrated 10 bale grapple. The Accumul8 increases the efficiency of handling small square bales while the reduced handling helps to eliminate leaf loss or broken bales from excess handling.

The Retriever allows one person to quickly gather and load wagons or highway trailers keeping your operation running efficiently.

The Accumul8 Retriever is a skid steer loader mounted bale accumulator with an integrated 10 bale grapple. The Accumul8 increases the efficiency of handling small square bales while the reduced handling helps to eliminate leaf loss or broken bales from excess handling.

The Retriever allows one person to quickly gather and load wagons or highway trailers keeping your operation running efficiently.

Retriever Configuration

When in the retrieving position both inner and outer bale guides are in the lowered position. The side rails are adjustable to accommodate 34″ – 40″ long bales.

Grappling Configuration

The bale guides are flipped up to allow tight grappling of bale packs from the field or when moving stacks.

Stable Stack

Each pack of 10 bales includes 2 bales positioned in the opposite direction. This cross-over pattern strengthens the stack by tying the bales together.

Integrated Grapple

The Retriever utilizes large hydraulically powered tines to pick up bale packs for quick loading and storage.

Toolless Changeover

Easily change between the grapple and the retriever without any tools.

Specifications	TLG10R
Capacity	10 Bales
Bale Length (min-max)*	34″ – 40″
Height	22″
Width	82″
Length	98.75″
Weight	905 LBS.
Hydraulic Cylinder	2-1/2 x 8
Grapple Hooks	24
Hydraulic Hoses	72″
Mount**	Skid Steer

* It is recommended that the bale length is twice the width of the bale for stable stacking.

** Comes standard with skid steer mount call for other options
