Sawdust Side Discharge Bucket- HLA Attachments
- Minimum 12 GPM required
- Hydraulic drive (coupled direct)
- Beater to prevent bridging
- Discharge from either side of machine
- 44″H x 57″L outside dimensions
- Two hydraulic motors on discharge belt (72″, 84″ & 96″ only)
- For Outside Width add 2-1/2″ to Inside Width dimension.
- Bolted adaptation for loader quick-tach. Easily convert to most loaders
| Part Number | Description | INSIDE WIDTH (INCHES) | HEAPED CAP. CU. YD. | APPROX. WEIGHT (LBS.) |
|---|---|---|---|---|
| SS60 | 60″ Side Discharge (Chevron Belt) | 60 | 1 1/2 | 1020 |
| SSC60 | 60″ Side Discharge (3/4″ Cleated Belt) | 60 | 1 1/2 | 1020 |
| SS72 | 72″ Side Discharge (Chevron Belt) | 72 | 1 7/8 | 1205 |
| SSC72 | 72″ Side Discharge (3/4″ Cleated Belt) | 72 | 1 7/8 | 1205 |
| SS84 | 84″ Side Discharge (Chevron Belt) | 84 | 2 1/8 | 1300 |
| SSC84 | 84″ Side Discharge (3/4″ Cleated Belt) | 84 | 2 1/8 | 1300 |
| SS96 | 96″ Side Discharge (Chevron Belt) | 96 | 2 1/2 | 1560 |
| SSC96 | 96″ Side Discharge (3/4″ Cleated Belt) | 96 | 2 1/2 | 1560 |
| LP102468 | Optional Agitator Speed Control Valve -Factory Installed Only | |||
| HK90 | Optional 90″ Hose Kit C/W Flat Faced Couplers | |||
| HK9090 | Optional 90″ Hose Kit c/w 90° Flat Faced Couplers | |||
| SHMK | Optional Spring Hose Mount Kit | |||
| Optional CAT 2 Three Point Hitch Mount c/w Tilting Cylinder |
HLA Side Discharge Buckets allow you to manage material faster than ever before. These amazing loader attachments are available in units for use with, but not limited to, sand, sawdust, or straw/
lime. The left or right discharge design eliminates the need for awkward manoeuvring, saving you even more time. Bolt on mounting options are available to fit most makes of material handlers. A three-point hitch setup is also available. Spare the shovel and save your back, get a Side Discharge Bucket for your material handling needs.
