Enorossi POWER RAKE “V” Frame Wheel Rake with Central Joint
Details
The POWER RAKE wheel rake is ideal for medium to small areas with an average amount of product to collect. Each arm has an independent movement so it is easier to adapt to the ground and have a great swath formation even on sloping terrain.
Standard Equipment
Rake wheel bearings: Tapered roller bearings
Rake wheel lifting: Hydraulic
Ground adaptation: Independent rake wheel arms
Ground pressure control: Spring system on frame and on each rake arm
Rake wheel frame ground clearance: 85 cm (2.8 ft)
Single-arm raking capability
Axle: Single axle (tandem optional)
Hitch: Clevis hitch
Optional Equipment
Wind guards for rake wheels
Wind guard for front rake wheel
Road lighting kit
Tandem axle kit
Towing eye
Italian approval for road circulation
Full Details
Enorossi has a wide range of wheel rakes, ideal for any farmer’s need.
The versatility of the wheel rakes make them suitable for harvesting grass, straw, corn stalks, sorghum and sugar cane.
It works by towing, therefore not using the PTO power take-off, it significantly reduces costs for the farmer and the environmental impact.
This feature, together with the low maintenance cost, makes this type of rake, with the same working width, the most convenient solution for the farmer.
The frame
Frame inline
Windrow width adjustment
Each model of wheel rake has the possibility to adjust the width of the windrow width: single system (formation of one windrow) or double passage in the field (formation of two windrows side by side) for models with in-line frame; hydraulic system in V-frame models with central joint; mechanical system in V-models with rear joint.Maximum working width (A) till to 12,10 meters (models EASY RAKE SUPERSTAR 22 SN ST).
Rake wheels
Standard rake wheel with 145 cm diameter and 6.9 mm diameter teeth for the models RP, RT, CADDY.
Standard rake wheel with 150 cm diameter and 7.5 mm diameter teeth for the models BATRAKE, MAXIMUS, EASY RAKE, EASY RAKE SUPERSTAR.
The Wind guards facilitate the process of unloading the forage from the rake wheels, avoiding it sticking to them and also helps not to disperse the product in windy conditions.
The Rubberflex wheel has been designed for heavy products and has the particularity of having short teeth and a very robust structure. With Rubberflex wheels it is also possible to increase the working speed.
Availabe from model MAXIMUS, EASY RAKE, EASY RAKE SUPERSTAR.
It is possible to adjust the ground pressure of the rake wheels according to the quantity of the product and the quality of the ground.
The adaptation of the rake wheels to the ground is very important, especially in conditions of disconnected terrain, therefore each model of rake has its own adjustment system.
This system allows to quickly switch from the work position to the transport position in a simple and fast way without getting off the tractor.
The hub of the rake wheels is grease lubricated, with tapered roller bearings, and sealed.
Additional information
Enorossi POWER RAKE “V” Frame Wheel Rake with Central Joint
Details
The POWER RAKE wheel rake is ideal for medium to small areas with an average amount of product to collect. Each arm has an independent movement so it is easier to adapt to the ground and have a great swath formation even on sloping terrain.
Standard Equipment
Rake wheel bearings: Tapered roller bearings
Rake wheel lifting: Hydraulic
Ground adaptation: Independent rake wheel arms
Ground pressure control: Spring system on frame and on each rake arm
Rake wheel frame ground clearance: 85 cm (2.8 ft)
Single-arm raking capability
Axle: Single axle (tandem optional)
Hitch: Clevis hitch
Optional Equipment
Wind guards for rake wheels
Wind guard for front rake wheel
Road lighting kit
Tandem axle kit
Towing eye
Italian approval for road circulation
